Parts List 9-37
Parts List 10.1 Tray 1 (MPT) Assembly - Service Parts List
No Part Number Name/Description
0. 050K61490 Fdr-Unit-MPT
1. Frame-MPT
2. Photo-Interrupter (Feed -Out Sensor #1)
3. Photointerrupter(REWORK) (OHP Sensor)
4. Lever-Handle-MPT
5. Spring-Handle
6. Lever-Hopping (Feed -Out Sensor #1 Actuator)
7. Plate-Earth(MPT)Front
8. Plate-Earth(MPT)Rear
9. Cover-Sensor(MPT) (Sensor Cover)
10. 032K04470 Guide Assy.-Friction
11. Guide-Sheet(MPT)
12. Shaft-Retard(Drive)
13. Spring-Reatrd
14. Plate-Retard
15. Shaft-Retard(Driven)
16. Roller-Retard
17. Plate-Arm(Front)Caulking
18. Gear-Link(Z27)Front
19. Lever-Link
20. Lever-Arm
21. Holder-Arm
22. Spring-Arm
23. Plate-Arm(Rear)Caulking
24. Gear-Link(Z27)Rear
25. Gear-Link-Z12
26. Shaft-Link
27. Spacer-Coupling
28. CS-RING (CS3-SUS)
29. Torque-Limiter-OTLV
30. Pin-Spring
