Xerox Phaser 7400 Service Manual

Parts List 9-39
63. Guide-Paper(MPT)-R (with 60~68)
64. Guide-Paper(MPT)-F
65. PINION GEAR B
66. WAVE WASHER B
67. Screw-T2D3-5
68. Plate-Friction
69. Lever-Lock(MPT)
70. Spring-Lever(MPT)
71. TappingScrew-B2 L=8 (included in Screw Kit)
72. Link-F(MPT)
73. Plate-Hook-Front
74. Link-R(MPT)
75. Post-Stay_Front
76. Post-Stay_Rear
77. Plate-Cover(Feeder) (Feed Roller Assy Cover)
78. Bush
79. Lever-Paper(MPT) (No Paper Sensor Actuator)
80. Spring-Paper(MPT)
81. TappingScrew-B2 L=8 (included in Screw Kit)
82. Cup_Screw (S Tight M3) (included in Screw Kit)
83. Roller-set-MPT-723
Parts List 10.1 Tray 1 (MPT) Assembly - Service Parts List
No Part Number Name/Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
