Xerox Phaser 7400 Service Manual

Parts List 9-41
Parts List 11.1 Exit Assembly - Service Parts List
No. Part Number Name/Description
0. 054K37720 Eject Assy
1. Guide-Eject-Assy
2. Guide-Eject
3. Roller-Eject
4. Plate-FG_Eject-R
5. Bush
6. Gear-Eject_Z17
7. Roller-Pinch-Eject
8. Spring-Torsion-Eject
9. Spring-Torsion-Eject
10. Holder-Lever
11. Lever-Exit Sensor (Fuser Exit Sensor Actuator)
12. Spring-SNS(F/R) (Fuser Exit Sensor Actuator Spring)
13. Photo-Interrupter (Fuser Exit Sensor)
14. Lever-Separator_DUP (Duplex Gate)
15. Spring-Separator_DUP (Duplex Gate Spring)
16. Lever-Separator_Sheet (Exit Gate)
17. DC-Solenoid-10SL-144 (Exit Gate Solenoid)
18. Guide-Sheet-FU-Assy (with 19~23)
19. Guide-Sheet-FU
20. Roller Assy.-FU
21. Spring-Torsion-FU
22. Spring-Torsion-FU
23. Shaft-Pinch
24. Lever-Paper-END (Job Offset Trailing Edge Sensor Actuator)
25. Spring-Paper-End(joboff)
26. Plate-FG-Eject-L3
27. Lever-Link-DUP (Duplex Gate Actuator)
28. Plate-FG-Eject-L1
29. Plate-FG-Eject-L2
30. Gear-Idle-Eject-Z54

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
