Xerox Phaser 7400 Service Manual

Parts List 9-45
Parts List 12.1 LED Assembly - Service Parts List
No. Part Number Name/Description
0. 015K77670 Plate-Top-Assy (LED Assembly)
1. Plate-Top-Welding
2. Chamber-Duct-Top (Top Cover Fan Duct)
3. Spoiler-FAN (Top Cover Fan Diffuser)
4. 127E15150 Motor-Fan (Top Cover Fan)
5. Holder-FAN-Intake
6. 019K13060 Holder-Head- Assy (with 7~19) (LED Head Holder Assy)
7. Holder-Head
8. Clump-Cable-Head
9. Spring-Torsion-100
10. Plate-Contact-Head-F
11. Plate-Contact-Head-R
12. Plate-Shutter-LED1
13. Gear-LED1
14. Gear-LED4
15. Spring-Torsion1
16. Limiter-torque
17. Post-shutter
18. Plate-FG-Head-FS
19. Pin
20. CONN Cord-JST4P-JST4P (LEDPWR Harness)
21. CONN Cord-JST10P-JST10P (LEDDATA Harness [YK])
22. CONN Cord-JST10P-JST10P (LEDDATA Harness [CM])
23. Plate-Top-Support
24. Plate-Pivot-Welding
25. Gear-Damper-TOP
26. Code-Cover-Top
27. Shaft-LED-Shutter
28. Gear-LED2
29. Gear-LED3
30. Limiter-torque

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
