Xerox Phaser 7400 Service Manual

Parts List 9-49
Parts List 13.1 Job Offset Assembly - Service Parts List
No. Part Number Name/Description
0. 054K37730 Job-Offset-Assy
1. Holder-Joboff-Lower
2. GEAR-IDLE-Eject_Z27
3. Pipe-Assy-Drive_723
4. Pipe-Assy-Driven_723
5. Bush-Shaft
6. Gear-Drive
7. Gear-Driven
8. Spring-Bush-L
9. Spring-Bush-R
10. Bracket-Motor(Caulking)
11. Motor-Resist (Job Offset Motor)
12. Gear-Idle-Z28
13. Gear-Link-Z60
14. Lever-Link-B
15. Lever-Link-A
16. Washer - 2W3
17. Cup_Screw (S Tight M 3) (included in Screw Kit)
18. CS-RING (CS3-SUS)
19. Ring
20. Cover-Motor_Joboff (Gear Cover)
21. Contact-Joboff-L
22. Contact-Joboff-R
23. Holder-Joboff-Upper
24. Lever-Stacker-Full-F (Top Output Tray Stack Full Feelers)
25. Lever-Stacker-Full-Sub (Top Output Tray Stack Full Sensor Actuator)
26. TappingScrew-B2 L=8 (included in Screw Kit)
27. Limiter-Pin
28. Spacer-Coupling
29. Ring

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
