Xerox Phaser 7400 Service Manual

Parts List 9-51
Parts List 14.1 Basket Assembly - Service Parts List
No. Part Number Name/Description
0. 674K01390 Basket Assy (Upper and Lower Assy)
1. Basket-Main-Assy (with 2~17, 49, 81~86) (Upper Basket Assy)
2. Plate-Bar
3. Plate-Lever-01
4. Lever-Basket-01
5. Lever-Basket-02
6. Post-Lever-01
7. Plate-Lock-01
8. Cover-Lock-Lever
9. Plate-Lock-02
10. Post-Lock-Lever
11. Lever-Basket-03
12. Spring-Lock-L
13. Lever-Stopper
14. Plate-Stopper
15. Post-Stopper
16. Spring-Stopper
17. Link-Unit-L (with18~35, 47~48) (Left Support Rail Assy)
18. Guide-Link-L
19. One-Way-Hinge-L
20. Plate-Damper-L
21. Rack-Damper-L
22. Spring-Lack-Damper-0.4
23. Link-Caulking-L
24. Post-Link-6
25. Bracket-Link-L
26. Post-One-Way
27. Washer-6-22
28. Ring
29. Cup_Screw (S Tight M 3) (included in Screw Kit)
30. Cup_Screw A (included in Screw Kit)
31. Gear-Damper
32. Plate-BKL
33. Plate-Support-BK
34. Plate-Link-L
35. Gear Assy.-L (with 36~46) (Left Damper Assy)

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
