Xerox Phaser 7400 Service Manual

Parts List 9-55
Parts List 16.1 Duplex Unit - Service Parts List
No. Part Number Name/Description
0. 084K35440 Duplex Unit
1. Frame Assy Uppper Left
2. Frame Assy Upper Right
3. Frame Lower
4. Lever-Sensor(F/R)
5. Spring-Sensor(F/R)
6. Photo-Interrupter
7. Roller-SwB
8. Roller-Feed-Dup
9. Bush
10. Bearing-Feed
11. Gear-Z40
12. Stopper-Gear
13. Motor-Assy-Dup Assy (Include:No.14~26)
14. Motor-Resist
15. Bracket-Motor-A-Caulking
16. Bracket-Motor-B-Caulkng
17. Gear-Z46/32
18. Gear-RE3
19. Pulley-MXL(25)
20. Collar
21. Shaft-Pulley
22. Bush
23. Bearing-Feed
24. Cup_Screw (S Tight M3) (included in Screw Kit)
25. Gear-Z26
26. Gear-Z44
27. Gear-RE3
28. Guide-Assy-Reverse Assy (Include:No.29~32)
29. Guide-Reverse
30. Lever-Sns-Reverse
31. Spring-Sns-Reverse
32. Stopper-Sns-RV

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
