Xerox Phaser 7400 Service Manual

Parts List 9-57
67. Spring-FG-Sns
68. Cover-Reverse- Assy (with 69,76)
69. Frame-Reverse-Assy (with 70~75
70. Frame-Reverse
71. Roller-Pinch
72. Holder-Roller-Pinch
73. Spring-Pressure-Pinch
74. Plate-Bracket-Spring
75. TappingScrew-B2 L=8 (included in Screw Kit)
76. Cover-Outer-Assy (with 77~82)
77. Cover-Reverse
78. Lever-Lock-Reverse
79. Spring-Lock-Reverse
80. Spring-FG-Reverse
81. Stopper-CR
82. TappingScrew-B2 L=8 (included in Screw Kit)
83. Plate-Assy-Lower (with 84~86)
84. Plate-Base-Lower
85. Lever-Sns-Dup2
86. Spring-SNS-Dup2
87. Guide-Paper-Reverse
88. Guide-Slide-F
89. Guide-Slide-R
90. Plate-Rail
91. Spring-Rail-Lock
92. Bracket-Guide-Slide-Caulking
93. Lever-Lock-CR
94. Plate-Lever-Lock
95. Shaft-Lock
96. Spring-Lock
97. TappingScrew-B2 L=8 (included in Screw Kit)
98. Cup_Screw (S Tight M3) (included in Screw Kit)
99. Screw (SW+2W) (included in Screw Kit)
Parts List 16.1 Duplex Unit - Service Parts List
No. Part Number Name/Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
