Xerox Phaser 7400

Wiring Diagrams 10-27
Front Sensor Board (2/2)
Front Sensor Board
MPTSNS
1
2
3
P/J433
1
3
2
OHP Sensor
+5VDC
MPTSNS
4
5
6
P/J450
1
3
2
Feed-Out Sensor #1
MPTSNS
7
8
9
P/J440
1
3
2
Tray 1 (MPT) No Paper Sensor
Interlock
s7400-371
Write
IN2
+5VDC
GND
OHP
+5VDC
GND
HOPMPT
+5VDC
GND
PAPMPT
Transfer Unit Entrance Sensor
Registration Sensor #1
