Xerox Phaser 7400 Service Manual

Wiring Diagrams 10-35
Motor Driver Board (5/6)
Engine Control Board Motor Driver Board
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
7
9
5
10
6
13
12
11
3
2
8
4
1
DRV0
NC
RESET
PAPIN2
HALBOX
PSWR
PAPIN
HOPMPT
GND
SBCNT2
GND
SBRXD
+5VPS
+5VPS
GAIN1
WTCWCCW
RXD
GND
SBPSIN
GND
KIDON
YIDCLK
KIDLOCK
YIDLOCK
KIDCLK
YIDON
GND
MIDCLK
GND
MIDLOCK
+5VF2
+5VF2
+5VF2
REGPWM
FG
24V
24V
+5VF2
HALL
MIDON
5V
5V
GND
GND
24V
24V
GND
UPCNT2
SBPSIN
DUPSDR
DUPDATA
DUPCLK
GND
SBTXD
+5VDC
24VDC
s7400-568

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
