Xerox Phaser 7400 Service Manual

Reference A-21
Finsher Tests - Tests the functionality of Finisher components.
Finisher Motor Tests - Tests the functionality of the motors by activating one motor at a time.
Test runs for 10 seconds or until the test is aborted.
Feed Motor Motor is On/Off <Press OK to start motor>
<Press Back or Cancel to abort>
<Auto abort in 10 seconds>
Saddle Roller Motor is On/Off
Bundle Motor
Forward
Motor is On/Off
Bundle Motor
Reverse
Motor is On/Off
Paddle Motor Motor is On/Off
Bundle Roller Motor is On/Off
Shift Motor Motor is On/Off
Order Motor Motor is On/Off
Staple Motor Motor is On/Off
Saddle Stiching
Motor
Motor is On/Off
SaddleTransfer
Motor
Motor is On/Off
Saddle Transfer
Motor
Motor is On/Off
Sliding Motor Motor is On/Off
Punch Motor Motor is On/Off
Punch
Registration
Motor
Motor is On/Off
Inverter Motor A Motor is On/Off
Inverter Motor B Motor is On/Off
Finisher Sensor/Switch Tests - Tests display the status each sensor or switch.
Entrance
Sensor
Entrance paper is Present / Not
Present
Tray Paper
Detection
Sensor
Media Present/Not Present
Tray Paper
Level Sensor
Media Present/Not Present
Service Diagnostics Tests and Utilities (Continued)
Menu Item Front Panel Display Results Functional Definition
