2. Press Display.
3. Click Graticule Label to turn graticule label display on or off.
Hiding Frequency Information
You can hide the frequency information from the screen in order to ensure
its confidentiality or for other reasons.
Hiding Frequency Information on the Screen
Follow the steps below to hide frequency information on the measurement
screen.
1. Press Display key.
2. Click Frequency to turn off the frequency display.
3. Turning off the frequency display using Display > Frequency key
does not erase the frequency display within the Stimulus
softkey, which is turned on by pressing Start, Stop, Center, and
Span. The display of the softkey bar itself can be switched on or
off by pressing Softkey On/Off.
Hiding Softkey's Frequency Information
You can delete the frequency information from the measurement screen,
which changes the frequency information displayed in the Stimulus softkey
and the data entry area for Hz unit to asterisks (***).
1. Press System key.
2. Click Service Menu, then click Security Level and select any of the
following options for the frequency display.
Softkey Function
None
Displays the frequency information.
Low
Hides the frequency information with a series of asterisks. This can
be turned to OFF by the Security Level menu.
High
Hides the frequency information with a series of asterisks. This
cannot be turned to OFF by the Security Level menu.
Resetting to OFF is only possible by executing Preset or Recall.
o Save/Recall > Save Trace Data & Save/Recall > Save
SnP is inactive when Security Level is set to Low/High.
Labeling a window
It is possible to assign a unique name to a channel and display it on the
screen. This feature is useful in saving and/or printing measurement result
for future reference.
Labeling a window
