Measurement
349
file is not located in the same folder as when the state was
saved.
• Pressing Save/Recall > Explorer executes Windows Explorer. This
helps you to browse the files in the ENA hard disk drive.
Recall Procedure Using "Recall by File Name" Feature
You can use the recall feature with the Recall by File Name softkey for files
you have named freely and saved in the D:\State folder. This function lets
you recall a file you have named freely and saved by simple softkey
operation, eliminating annoying operation using the Open dialog box.
• Although there is no limit to the number of files saved in a
folder, only up to 50 files are displayed on the softkeys. If more
than 50 files are saved in a folder, they are sorted in the order
of numbers 0 to 9 and alphabetic characters A to Z and the first
50 files are displayed as softkeys.
Although there is no limit to the number of characters of a file
name, only up to 12 characters are displayed on the softkey. If
a file name exceeds 12 characters, the first 12 characters are
displayed on the softkey and the remaining characters are
omitted and replaced with "...".
• Different files may be displayed on softkeys with the same
name or a saved file is not displayed on any softkey because of
the above limitations.
1. Press Save/Recall key
2. Click Recall by File Name.
3. Files that have been named and saved in the D:\State folder are
displayed on softkeys. Press the key for the file you want to recall.
Priority of Recalling Configuration File at Startup
If several instrument configuration files exist at the startup of the E5071C,
only one file is recalled and set at a time in the following order of priority.
If these files do not exist, the normal preset (factory preset) is executed.
Priority Recalled file
1
Configuration file for the auto-recall function in the A drive (If
external floppy disk drive is connected.)
2 Configuration file for the auto-recall function in the D drive
3
Configuration file for the user-preset function in the D drive.
