E5071C
756
Error Messages
Error Messages
An error message is displayed against a red background in the instrument
message/warning area in the lower left part of the screen. Pushing a front
panel key or executing :DISP:CCL command clears the error message.
Errors caused by the operation of a front panel key simply appear on the
display. They are not stored in the error queue with some exceptions.
An error with a positive error number is one uniquely defined for this
instrument. On the other hand, an error with a negative error number is
basically one defined for common GPIB devices in IEEE488.2
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
A
No. Message Description
20
Additional
standard
needed
The GPIB command that turns ON the calibration
function has been sent before all the data
measurements required to calculate the
calibration factor have been completed.
In 1-port calibration, for example, when the
measurements are completed for OPEN and
SHORT standards but not for LOAD standard.
This error occurs when you try to turn ON the
calibration function by calculating 1-port
calibration coefficient using
SENS:CORR:COLL:SAVE or
SENS:CORR:OFFS:COLL:SAVE.
Be sure to measure all the necessary calibration
data before sending commands. This error is not
generated by front key operations.
58
Auto port
extension
not allowed
An auto port extension element has been
received at a position where this instrument does
not accept one.
B
No. Message Description
- Block A block-data element has been received at a
