Trigger System
• Overview
• System-Wide States and Transitions
• Channel-wide States and Transitions
Other topics about Making Measurement
Overview
The trigger system is responsible for such tasks as detecting the start of a
measurement cycle (triggering) and enabling/disabling measurement on
each channel. As shown the following figure, the trigger system has two
types of states: system-wide and channel-wide. The system-wide state can
be "Hold", "Waiting for Trigger", or "Measurement", while the channel-wide
state can be "Idle" or "Initiate".
Trigger system
To Next Page
