E5071C
1072
Analysis in Time Domain (time domain function)
• Overview
• Transforming Measurement Data to Time Domain
• Sample Program
Other topics about Analyzing Data
Overview
The time domain function provides the following functions:
• Transforming measurement data to data in the time domain
(Transformation Function)
• Deleting unnecessary measurement data in the time domain (Gating
Function)
Transforming Measurement Data to Time Domain
By using the Transformation Function, you can convert the results
measured in the frequency domain to data in the time domain and analyze
it.
On/Off
To turn on or off the transformation function, use the following command:
:CALC{1-36}:TRAN:TIME:STAT
Selecting Transformation Type
To select the transformation type (band pass/low pass), use the following
command:
:CALC{1-36}:TRAN:TIME
To select the stimulus type (impulse/step) when the transformation type is
low pass, use the following command:
:CALC{1-36}:TRAN:TIME:STIM
When the transformation type is low pass, you need to execute the
following command because each measurement point must be a multiple of
the start frequency.
:CALC{1-36}:TRAN:TIME:LPFR
Setting Window Shape
To set the window shape, use one of the following items.
Item Command
β
:CALC{1-
