Rear Panel: Names and Functions of Parts
1. Handler I/O Port
The terminal to which an automatic machine (handler) used on a
production line is connected. See Handler I/O Port.
Connector type: 36-pin Ribbon (Centronics) connector
2. Ethernet Port
A terminal for connecting the E5071C to a LAN (Local Area Network).
Connecting this instrument to a LAN enables you to access the hard disk
drive of this instrument from an external PC or to control this instrument
by using SICL-LAN or telnet.
Specification Value
Connector
type
8-pin RJ-45 connector
Base standard
10Base-T/100Base-TX Ethernet (automatic data rate
selection)
3. External Monitor Output Port (Video)
A terminal to which an external color monitor (display device) can be
connected. By connecting a color monitor to this terminal, the same
information shown on the LCD screen of the main body can be displayed
on an external color monitor.
Connector type: 15-pin VGA connector, female
4. GPIB Connector
The connection of an external controller through General Purpose Interface
Bus (GPIB) connector allows you to configure an automatic measurement
system.
This GPIB connector is used only for controlling the E5071C from an
external controller. Use USB/GPIB interface to control other devices from
the E5071C. You cannot control other devices from the E5071C through
this GPIB connector.
5. External Trigger Input Port (Ext Trig)
A connector to which external trigger signals are input. This connector
detects the downward transition from the HIGH state in TTL signals as the
trigger signal. To use this connector to generate a trigger, you must set
