Overview of Fixture Simulator
• Overview
• Functions for Single-Ended (Unbalanced) Port
Other topics about Fixture Simulator
Overview
The Fixture Simulator is a function that uses software in the E5071C to
simulate various measurement conditions based on the measurement
results. The functions available in Fixture Simulator are as follows:
• Network de-embedding
• Port reference impedance conversion
• Matching circuit embedding
• 4-port network embedding/de-embedding
• Balance-unbalance conversion
• Differential/Common port reference impedance conversion
• Differential matching circuit embedding
Data processing flow diagram of fixture simulator
