Key Name Description
Knob
(turned clockwise or
counterclockwise)
Moves the softkey selection (highlighted display)
up or down.
Keys
Moves the softkey selection (highlighted display)
up or down.
Key
Displays the softkey menu one layer above.
Key
Displays the softkey menu one layer below.
Knob or Enter key (pressed)
Executes the function of the selected softkey.
After pressing the data entry softkey, the focus automatically moves to the
data entry area.
When the focus is on the data entry area (data entry area is selected)
When the focus is placed on the data entry area (the data entry bar is
displayed in blue), the NAVIGATION Block keys work as described below.
Key Name Description
Knob
(turned clockwise or
counterclockwise)
Increases or decreases the numeric value in the data
entry area in small steps.
Keys
Increases or decreases the numeric value in the data
entry area in large steps.
Keys
Moves the cursor (|) in the data entry area laterally back
and forth. Use it together with the ENTRY Block keys to
change data one character at a time.
Knob or Enter key
(pressed)
Finishes the entry in the data entry area and moves the
focus to the softkey menu.
8. ENTRY Block
A group of keys used for entering numeric data is provided on the front
panel of the E5071C.
Key Name Description
0, 1, 2, 3 .....
9 , .
Keys
Type numeric characters or a decimal point at the position of the
cursor in the data entry area.
