Measurement
399
2. Execute the 2-port ECal.
Setup Description Key Operation
Executing a 2-port ECal between test
ports 1 and 2
Cal > ECal > 2 Port ECal
> Port 1-2
5. Connect the DUT
The DUT is connected across test ports 1 and 2.
Connecting the DUT
