Shows whether the fixture simulator is turned ON or OFF.
Sim (displayed in blue) Fixture simulator: ON
(not displayed) Fixture simulator: OFF
5-15. Averaging Status
Displays the averaging factor and averaging count when averaging is
turned on.
n/m (displayed in blue)
Averaging: ON
(m: averaging factor; n: averaging count)
(not displayed) Averaging: OFF
5-16. Sweep Range
Indicates the sweep range by using the start/stop or center/span.
5-17. IF Bandwidth/CW Frequency
Indicates the IF bandwidth when the sweep type is linear/log frequency or
the CW frequency when the sweep type is power.
5-18. Channel Number
Indicates the channel number.
5-19. Graticule Labels
Y-axis divisions in the rectangular display format. When traces in the
rectangular display format are overlaid, the Y-axis divisions for the active
trace are displayed. The value of the reference line (the division line
between and ) is entered numerically by opening the data entry bar
using the keys: Scale Key + Reference Value. You can change values of
the reference line at one-division intervals by placing the mouse pointer in
the area of the graticule label (the pointer changes from to ), moving
the pointer vertically with the left mouse button pressed, and then
releasing the button at the desired location.
5-20. Bandwidth Parameters
Turning on the bandwidth search function displays the bandwidth
parameters here. For more on the bandwidth search function, see
Determining the Bandwidth of the Trace (Bandwidth Search).
