E5071C
390
List State
Toggles ON/OFF the state of each segment; the row for
setting (State) only appears in the segment table when this
is ON
5. Enter each item in the following table for each added segment (line)
to create the segment table. To create the segment table, use the
hardkeys and softkeys.
Start
Sets the start value of the sweep range
Stop
Sets the stop value of the sweep range
Center
Sets the center value of the sweep range
Span
Sets the span value of the sweep range
Points
Sets the number of points
IFBW
Sets the IF bandwidth
Power
Sets the power level; the power range is common to the
settings for the linear/log sweep (Sweep Setup key > Power
Ranges)
Delay
Sets the sweep delay time
Sweep
Mode
Sets the sweep mode; you need to select one of the
following items:
STEPPED: Stepped mode
SWEPT: Swept mode
Time
Sets the sweep time; to specify the auto setting (AUTO),
enter 0 as the sweep time
State
Sets the state of each segment
Useful functions when using a mouse
By right-clicking on the selected cell, you can use the following shortcut
menu.
Shortcut Function
Copy
Copies the value in the selected cell into the clipboard (internal
temporary storage memory)
