Agilent Technologies E5071C User Manual

E5071C
810
Meas
Key Operation Default value Preset *RST Save/Recall
S11
← ←
√
Sss11
(When Fixture Simulator is
set on, set Topology at
SE-Bal, and, BalUn on in
Analysis mode)
← ←
√
Sdd11
(When Fixture Simulator is
set on, set Topology at
Bal-Bal, and BalUn on in
Analysis mode)
← ←
√
Sss11
(When Fixture Simulator is
set on, set Topology at
SE-SE-Bal, and BalUn on
in Analysis mode)
← ←
√
Absolute A(1)
← ←
√
Aux
Input
1
Range 10 V
← ←
√
Sweep
Port
1
← ←
√
Aux
Input
2
Range 10 V
← ←
√
Sweep
Port
1
← ←
√
