Agilent Technologies E5071C User Manual

E5071C
92
1. Press Channel Prev/Channel Next to select the channel for which you
want to set the correction coefficient.
2. Press Sweep Setup key, then click Power > Slope [xxx dB/GHz] where
“xxx” represents the current set value and input the correction
coefficient using the ENTRY block keys on the front panel.
Setting the Number of Points
The number of points is the number of data items collected in one sweep.
It can be set to any number from 2 to 1601 for each channel
independently.
• To obtain a higher trace resolution against the stimulus value,
choose a larger value for number of points.
• To obtain higher throughput, keep the number of points to a smaller
value within an allowable trace resolution.
• To obtain higher measurement accuracy after calibration, perform
calibration using the same number of points as in actual
measurements.
• When the upper limit of the number of channels and traces is
set to 1Ch / 4 Tr 20001 Points, the maximum number of
measurement points will be 20001.
Setting the number of points
1. Press Channel Next/Channel Prev keys to select the desired channel.
2. Press Sweep Setup key.
3. Click Points, then input the desired number of points.
Setting the Sweep Time
Sweep time is the time it takes to complete a sweep for each stimulus
(source) port. Two modes are available for setting the sweep time: manual
sweep time mode and automatic sweep time mode.
Manual
Sweep Time
Mode
In this mode, the sweep time is set manually. Once the
sweep time is set, changes in measurement conditions will
not affect the sweep time as long as it is within the analyzer's
capability. If the sweep time becomes lower than the
analyzer's lower sweep time limit, the sweep time will be
reset to the shortest time within the conditions. If the sweep
time exceeds the analyzer's upper sweep time limit, the
sweep time will be reset to the longest time within the
conditions.
Automatic
Sweep Time
Mode
The sweep time is always kept to the shortest time possible
with the current measurement conditions.
