E5071C
396
2. Create a Segment Sweep Table
Follow the steps below to make entries in the segment sweep table.
1. Display the segment table.
Setup Description Key Operation
Presetting
Preset > OK
Displaying the segment table
Sweep Setup > Edit Segment Table
2. Display the IF bandwidth setting column in the segment table.
Setup Description Key Operation
Moving the focus to the softkey menu
Focus
Display of IF bandwidth setting column: ON
List IFBW (turn it ON)
When setup items (power level, delay time, sweep mode, and sweep
time in this case) are not displayed in the segment table, the setting
for the channel in use applies to all segments.
3. Enter the setup data in the segment table.
Setup Description Key Operation
Moving the focus to the segment table
(select)
Focus
Segment 1
Start frequency: 440 MHz
4 > 4 > 0 > M/µ
Stop frequency: 915 MHz
9 > 1 > 5 > M/µ
Number of points: 47
4 > 7 > x1
IF bandwidth: 70 kHz
7 > 0 > k/m
Segment 2
Start frequency: 915 MHz
9 > 1 > 5 > M/µ
Stop frequency: 980 MHz
9 > 8 > 0 > M/µ
To Next Page
