Selecting the Measurement Parameter
To select the measurement parameter, use the command that matches
your selected device type, as identified in the following table:
Device Type Command
Unbalance-balance
:CALC{1-36}:FSIM:BAL:PAR{1-36} :SBAL
Balance-balance
:CALC{1-36}:FSIM:BAL:PAR{1-36} :BBAL
Unbalance-unbalance-balance
:CALC{1-36}:FSIM:BAL:PAR{1-36} :SSB
Differential Matching Circuit Embedding
The Differential Matching Circuit Embedding feature simulates the
characteristics the DUT would exhibit if a balance-unbalance converted
differential port were connected to a matching circuit after being subjected
to balance-unbalance conversion.
On/Off
To turn on or off Differential Matching Circuit Embedding, use the following
command:
:CALC{1-36}:FSIM:BAL:DMC:STAT
You can only turn on or off Differential Matching Circuit Embedding for all
of the ports, not for each balance port individually. However, any balance
port whose circuit type is set to "None" behaves as if this feature were
permanently off.
Configuring the Matching Circuit Settings
To select a circuit type, use the following command:
:CALC{1-36}:FSIM:BAL:DMC:BPOR{1-2}
To set the circuit constant, use the following commands:
Circuit constant Command
C
:CALC{1-36}:FSIM:BAL:DMC:BPOR{1-2}:PAR:C
G
:CALC{1-36}:FSIM:BAL:DMC:BPOR{1-2}:PAR:G
L
:CALC{1-36}:FSIM:BAL:DMC:BPOR{1-2}:PAR:L
R
:CALC{1-36}:FSIM:BAL:DMC:BPOR{1-2}:PAR:R
When you want to use a user file to define the circuit type, specify the file
using the following command:
To Next Page
