Quick Start
43
5-21. Marker Numbers
The marker values are displayed in a list at positions 5-21, 5-22, and 5-23.
Position 5-21 displays the marker numbers. For the active marker (the one
for which setup and analysis are being performed), > is displayed to the left
of the marker number. For the reference marker, is displayed instead
of the marker number.
5-22. Marker Stimulus Values
The marker stimulus value for each marker (the frequency/power level at
the marker point) is displayed here.
5-23. Marker Response Values
The marker response value for each marker (the measurement value at
the marker point) is displayed here. Two (or three) response values are
displayed for data in Smith chart or polar display format.
5-24. Markers
The markers used for reading values on a trace. Up to 10 markers can be
displayed for each trace.
Active marker (the one for which setup and analysis are being
performed)
Non-active marker
Here, "n" denotes a marker number. For the reference marker, however,
nothing is displayed at the location of n. Clicking the marker or one of the
Marker Indicators makes the marker active.
5-25. Marker Indicators
Indicates the positions of markers on the stimulus axis.
Active marker indicator
Non-active marker indicator
