Agilent Technologies E5071C User Manual

Measurement
227
3. Using Adaptor Removal:
a. Perform a SOLT/TRL F2P Calibration at P band WG (Z0 = 1)
b. Perform Adapter removal at port 1 (Z0=50) using 85052D
4. Using Port Extension:
a. Perform a SOLT F2P calibration at Port 1 (3.5mm) with Z0 =
50
b. Perform Port extension calibration at Port 2 (manual with Coax
length, WG length, Cut off). System Z0 can be either 1 oh or
50 ohm; both are fine to use.
