Agilent Technologies E5071C User Manual

Measurement
179
Sliding and Offset Load Calibration
• Supported Calibration
• Sliding Load Calibration
• Offset Load Calibration
Other topics about Advanced Calibration
Supported Calibration
The following table shows the supported calibration for the sliding load and
offset load.
Calibra
tion
SO
LT
Respo
nse
Enhan
ced
Respo
nse
TR
L-
Li
ne
Adapt
er
Remo
val
Scal
ar
Mix
er
Vec
tor
Mix
er
(VB
A)
Sliding
Load
Yes Yes Yes
Ye
s
Yes No No
Offset
Load
Yes No Yes No No No No
Sliding Load Calibration
A sliding load is defined by making multiple measurements of the device
with the sliding load element positioned at various marked positions of a
long transmission line. The transmission line is assumed to have zero
reflections and the load element has a finite reflection that can be
mathematically removed using a least squares circle fitting method.
A sliding load calibration can be very accurate when performed perfectly. It
can also be very inaccurate when not using proper technique. For accurate
results, follow the users manual instructions closely.
The following calibration kits are supported:
• 85050B 7 mm Calibration Kit
• 85052B 3.5 mm Calibration Kit
• 85054B 50 Ohm Type-N Calibration Kit
• 85056A 2.4 mm Calibration Kit
Procedure
