Quick Start
27
(numeric
keys)
+/- & Key
+/- alternately changes the sign (+, - ) of a numeric value in the data
entry area.
is the backspace key.
+/- key works only when there are no numerical values in the entry
area. When a numerical character is entered in the entry area, the
+/- key transforms into (
) backspace key.
G/n, M/u,
k/m, x1
Keys
Adds a prefix to the numeric data typed by using the numeric key and
+/- key and then enters that data. One of the two prefixes written on
the surface of the key is automatically selected depending on the
parameter to be entered. x1 is entered without a prefix.
Softkey
On/Off ,
Entry Off
Key
Turns off the data entry bar if it is displayed. If the dialog box is
displayed, cancels the entry and closes the dialog box. If the data
entry bar and dialog box are not displayed, turns the softkey menu
display on/off.
Help Key
Displays online help for E5071C.
Focus Key
Changes the selection (focus) among the objects to be manipulated
by the NAVIGATION Block keys and ENTRY Block keys. The objects to
be manipulated by the NAVIGATION Block keys and ENTRY Block keys
include softkey menus, data entry areas, tables (e.g., segment
tables, limit tables, and marker tables), and dialog boxes. When two
or more of these are displayed on the screen and need selecting, use
this key to change the selection (focus) among the objects to be
manipulated. When a softkey menu is selected, the menu name area
at the top of the menu is displayed in blue. When a data entry area is
selected, the data entry bar is displayed in blue. When a table is
selected, the frame of the table window is displayed in light gray.
While a dialog box is displayed, the focus is fixed on the dialog box
and cannot be changed.
9. INSTR STATE Block
A group of keys related to the macro function, store and call function,
control/management function, and the presetting of the E5071C (returning
it to the preset state).
Key Name Description
Macro Setup
Key
Displays the Macro Setup Menu on the right side of the screen.
Manipulating the Macro Setup Menu enables you to start up the
VBA editor or to create, call, or store a VBA project.
Macro Run Key
Executes a VBA procedure called "main" that has a VBA module
named Module1.
Macro Break
Stops the VBA procedure being executed.
