Measurement
313
Softkey Function
Limit
Test
Sets the limit test ON/OFF.
Limit
Line
Sets the limit line display ON/OFF.
Edit Limit
Line
Opens the limit table for editing the limit line. See
Defining_the_limit_line.
Limit line offset
By adding a certain offset to the limit value, you can adjust the limit line so
that it conforms to the device output.
1. Press Channel Next/Channel Prev keys and Trace Next/Trace prev keys
to select the trace on which the limit test function will be used.
2. Press Analysis key to display the Analysis menu.
3. Click Limit Test to display the softkeys for the limit test.
4. Click Limit Line Offsets to display the limit line offset function menu.
The following functions correspond to each softkey.
Softkey Function
Stimulus
Offset
Adds a certain offset to the stimulus value of the
entire segment in the limit table. (Stimulus offset)
Amplitude
Offset
Adds a certain offset to the response value of the
entire segment in the limit table. (Amplitude
offset)
Marker ->
Amp. Ofs.
Adds the amplitude offset by the same amount as
the retrieved value of the active marker . You can
confirm the current value set for the amplitude
offset by pressing Amplitude Offset. (Marker
amplitude offset)
Stimulus offset
To Next Page
