E5071C
438
Evaluating Transmission Characteristics of a Front End Module
• Overview
• Procedure
Other Measurement Examples
Overview
This example shows how to measure the transmission characteristics of a
6-port front end module, as shown in the following figure, by using the
E5071C and the E5091A.
Procedure
In this example, a DUT is evaluated according to the procedure shown in
table below.
Procedure Description
1. Determining Measurement
Conditions
Determine the measurement
conditions such as the sweep
conditions and measurement ports.
2. Setting Channel Window Allocation
Set the allocation of the channel
windows on the screen.
3. Setting the Test Ports
Determine the test port assignment
for each channel.
To Next Page
