E5071C
446
Executing Power Calibration
• Overview
• Procedure
Other Measurement Examples
Overview
This section shows an example of executing power calibration using the
E4418B power meter and the E4412A power sensor.
• Power calibration may not be executed when the specified
frequency and level is out of range of the power sensor
specification.
Procedure
In this example, power calibration is executed according to the steps
shown in table below.
Step Description
1. Connecting Power
Meter
Connects the power meter to the E5071C.
2. Selecting Power Meter
a. Setting Address of
GPIB Power Meter
b. Setting USB Power
Meter
Configures the power meter's USB/GPIB
interface and GPIB address with the
E5071C.
3. Setting Stimulus
Condition
Sets conditions such as the power level and
frequency.
4. Executing Zero
Adjustment and
Calibration of Power
Sensor
Executes zero adjustment and calibration of
the power sensor.
5. Setting Calibration
Data Measurement
Conditions
Selects the port, selects the power sensor,
sets the number of measurements at one
point, and sets the tolerance during power
calibration.
6. Connecting Power
Connects the power sensor.
To Next Page
