E5071C
1040
Point Trigger Function
• Point Trigger
• Switching Mode
Other topics about Making Measurement
Point Trigger
Point trigger is a method used to measure a single point each time the
instrument is triggered. You can perform this type of measurement by
turning ON/OFF the point trigger function.
Switching Mode
You can use the following command to toggle between the point trigger's
ON/OFF status.
:TRIG:POIN
• If the trigger source is internal, the point trigger function does
not work even if it is specified to ON.
Low-latency external trigger
When the trigger source is an external trigger and the point trigger
function is on, the low-latency external trigger function is available. The
low-latency external trigger function is used to set the external trigger
delay time each time a trigger for a measurement point is given.
The setting of the low-latency external trigger function is valid for all
channels.
Setting the low-latency external trigger
To toggle ON/OFF the low-latency external trigger function, use the
following command:
:TRIG:EXT:LLAT
If the trigger source is not an external trigger, the low-latency external
trigger function does not work even if it is specified to ON, nor does it work
when the point trigger function is off.
To set the external trigger delay time, use the following command:
:TRIG:EXT:DEL
