E5071C
24
Trace
Prev Key
Selects the previous trace as the active trace. (Each time the key is pressed
causes the active trace to step down from the trace with the currently
designated number to one with a smaller trace number.)
4. RESPONSE Block
A group of keys used mainly for setting up response measurements on the
E5071C.
Key
Name
Description
Channel
Max Key
Changes between normal and maximum display of the active channel
window. In normal display, all of the defined channel windows (both active
and non-active) are displayed in split views on the screen. In maximum
display, only the active channel window is displayed over the entire area,
with non-active windows not displayed. To maximize the active channel,
double-click the channel window frame. Measurements are also carried out
on the non-active channels that are not displayed.
Meas Key
Displays the Measurement Menu on the right side of the screen.
Manipulating the Measurement Menu enables you to specify the
measurement parameters (types of S-parameters) for each trace.
Format
Key
Displays the Format Menu on the right side of the screen. Manipulating the
Format Menu enables you to specify the data format (data transformation
and graph formats) for each trace.
Scale Key
Displays the Scale Menu on the right side of the screen. Manipulating the
Scale Menu enables you to specify the scale for displaying a trace
(magnitude per division, value of the reference line, etc.) for each trace. You
can also specify the electrical delay and phase offset for each trace.
Display
Key
Displays the Display Menu on the right side of the screen. Manipulating the
Display Menu enables you to specify the number of channels and the
channel window array, the number and arrangement of traces, the setup for
data math, etc.
Avg Key
Displays the Average Menu on the right side of the screen. Manipulating the
Average Menu enables you to define the averaging, smoothing, and IF
bandwidth.
Cal Key
Displays the Calibration Menu on the right side of the screen. Manipulating
the Calibration Menu enables you to turn the calibration and error correction
on/off and change definitions for calibration kits.
5. STIMULUS Block
A group of keys for defining the stimulus values (signal sources and
triggers).
Key
Name
Description
