Measurement
79
Active Channel
The active channel is the one whose settings can currently be changed.
The window frame of the active channel is displayed brighter than the
window frames of the other channels. To change the settings specific to a
certain channel, you must first activate the channel.
To change the active channel, use the following hardkeys:
Hardkey Function
Channel
Next
Change the active channel to the next channel with the
larger channel number.
Channel
Prev
Change the active channel to the previous channel with the
smaller channel number.
Active trace
The active trace is the one whose settings can currently be changed. The
trace name on the screen (for example, Tr3) of the current active trace is
highlighted and indicated with
to the left. To change the settings specific
to a certain trace, you must first activate the trace.
To select the active trace, use the following hardkeys:
Hardkey Function
Trace
Next
Change the active trace to the next trace with the larger
trace number.
Trace
Prev
Change the active trace to the previous trace with the
smaller trace number.
Setting Parameter for each Setup Item (Analyzer, Channel, Trace)
The following table lists the setting parameters and indicates the setup
item (analyzer, channel, or trace) that each parameter controls along with
the applicable setup key(s).
Parameter Controlled Setup Items Setup Key(s)
Analyz
er
Chann
el
Trac
e
Stimulus Settings
Sweep range x
Start, Stop, Center, Span
Power, CW frequency x
Sweep Setup > Power
