Measurement
447
Sensor
7. Measuring Calibration
Data
Executes the measurement of calibration
data.
1. Connecting Power Meter
Connect the GPIB connector on the E4418B (GPIB address: 14) to the
E5071C through USB/GPIB Interface.
• From Firmware revision 9.2, E5071C supports USB enabled
power sensors. When you connect USB enabled power sensor
for the first time, new hardware wizard runs. For more
information, refer to Setting system controller (USB/GPIB
interface)
2. Selecting Power Meter
Follow the steps to select the power meter
Setting Description Key Operation
USB/GPIB System > Misc Setup > Power
Meter Setup > Select Type >
USB/GPIB
Setting Address of GPIB Power Meter
Follow these steps to configure the power meter's GPIB address.
Setting Description Key Operation
GPIB address of the power meter:
14
System > Misc Setup > GPIB Setup
> Power Meter Address > 1 > 4 >
x1
• You can also set the GPIB address of power meter by pressing
System > Misc Setup > Power Meter Setup > GPIB Address
Setting USB Power Meter
Follow these steps to configure the USB power meter
Setting Description Key Operation
USB power meter System > Misc Setup > Power
Meter Setup > USB
3. Setting Stimulus Condition
Follow these steps to configure the stimulus conditions:
Setting Description Key Operation
