E5071C
874
For more information on definition of calibration kit, refer to
http://na.tm.agilent.com/pna/caldefs/stddefs.html
• From firmware A.09.10, the number of calibration kit definition
is increased from 20 to 30 and number of sub class is increased
from 8 to 30.
ECal (electronic calibration) kit
The ECal supported by E5071C are defined below:
Model Name Connector Type Frequency Range
85091B 7 mm 300 kHz to 9 GHz
85091C 7 mm 300 kHz to 9 GHz
85092B Type N 300 kHz to 9 GHz
85092C Type N 300 kHz to 9 GHz
85093B 3.5 mm 300 kHz to 9 GHz
85093C 3.5 mm 300 kHz to 9 GHz
85096B Type N, 75 ohm 300 kHz to 3 GHz
85096C Type N, 75 ohm 300 kHz to 3 GHz
85098B 7-16 300 kHz to 7.5 GHz
85098C 7-16 300 kHz to 7.5 GHz
85099B Type F 300 kHz to 3 GHz
85099C Type F 300 kHz to 3 GHz
N4431A 3.5 mm, Type N 300 kHz to 9 GHz
N4431B 3.5 mm, Type N 9 kHz to 13.5 GHz (see note)
N4432A Type N 300 kHz to 18 GHz
N4433A 3.5 mm 300 kHz to 20 GHz
N4690A Type N 10 MHz to 18 GHz
N4690B Type N 300 kHz to 18 GHz
