E5071C
168
User-characterized ECal
• Overview
• Precautions to take in using VBA macros
• Storing user characteristics to the ECal module
• Backup/recovery of ECal module's built in flash memory
• Executing User characterized ECal
Other topics about Calibration with ECal
Overview
The E5071C allows you to execute ECal calibration with user-defined
characteristics instead of the ECal characteristics defined as the factory
default. This feature is called User-characterized ECal, and it is used to
execute ECal calibration when an adapter is connected to the ECal module.
Before executing the User-characterized ECal, you have to measure data,
such as characteristics when the adapter is connected to the ECal module,
and store them to the built-in flash memory of the ECal module as the user
characteristics.
Use the following VBA macro to acquire user characteristics and store them
to the ECal module's built-in memory.
Storage folder VBA macro name (project name)
D:\Agilent EcalCharacterization.vba
Precautions to take in using VBA macros
• Never connect/disconnect the USB cable while executing the VBA
macro.
• In particular, the above precaution must always be observed
while the VBA macro is storing data to the ECal module's built-in
flash memory; disconnecting the USB cable at this time may
damage the ECal module.
• Back up the flash memory contents.
The VBA macro provides a feature to back up the contents of the
ECal module's built-in flash memory. Before storing user
characteristics to the ECal module, be sure to use this feature to
back up the flash memory's current contents.
Storing user characteristics to the ECal module
To Next Page
