E5071C
418
Measuring the Deviation from a Linear Phase
• Overview
• Procedure
Other Measurement Examples
Overview
This section illustrates how to determine the deviation from a linear phase
in the pass band of a 1.09-GHz bandpass filter.
Procedure
Here, the DUT is evaluated by following the steps.
Step Description
1. Connect the DUT The DUT is connected.
2. Define the
Measurement Conditions
The measurement conditions are defined.
3. Execute the
Calibration
The calibration is executed.
4. Connect the DUT and
Execute the Auto Scale
The DUT is connected again to execute the
auto scale function.
5. Specify the Electrical
Delay
The electrical delay is specified.
6. Measure the Deviation
from a Linear Phase
The statistics data function (peak-to-peak)
is used to determine the deviation from a
linear phase.
1. Connect the DUT
Connect the DUT as shown below.
