E5071C
828
Troubleshooting
Troubleshooting
This section describes the steps you should take when you believe the
Agilent E5071C is operating improperly. The results of these simple
investigative procedures may help you avoid the down-time and
inconvenience of repair service. The troubleshooting instructions are
divided into three categories.
When taking all solution but it does not work. Contact Agilent Technology's
Customer Contact.
• Troubleshooting during Startup
• Troubleshooting during Operation
• Troubleshooting for External Devices
Troubleshooting during Startup
Symptom Solution
Turning on (|) the standby switch does
not start up the system.
• Confirm that the
power cable is
properly plugged in.
• Confirm that the line
switch on the rear
panel is turned on.
The system starts up, but it automatically
shuts down immediately.
Execute the system
recovery.
The system starts up, but it enters the
service mode (The instrument status bar
in the lower right part of the screen
displays SVC in red).
Execute the system
recovery.
The measurement screen appears after
startup, but the date and time displayed
on the instrument status bar in the lower
right part of the screen differ greatly from
the previous settings.
Execute the system
recovery.
The measurement screen appears after
startup, but the power-on test is failed,
with Error Message 241 appearing against
a red background in the instrument
Execute the system
recovery.
To Next Page
