Measurement
385
• The start frequency of segment 1 must be greater than lowest
frequency and the stop frequency of the last segment less than
highest frequency, as per the frequency range depending on the
option.
• When the start frequency and stop frequency of a segment are not
the same, you can define from 2 to 1601 points in a segment.
• When the start frequency and stop frequency of a segment are the
same, you can define from 1 to 1601 points in a segment.
• You can set the total number of points in the segment table from 2
to 1601.
• You can set the number of segments in the segment table to
between 1 and 201.
• You can turn ON or OFF segments.
Items that can be set for Each Segment
For the segment sweep, you can set the sweep range, the number of
points, IF bandwidth, power level, sweep delay time, sweep mode, sweep
time and segment ON/OFF for each segment.
You can set the items in the following table to ON/OFF for each segment. If
you enable the segment-by-segment setting, you can make the setting for
each segment in the segment table; if you disable it, the setting in the
following table is used.
Item When segment-by-segment setting is disabled
IF bandwidth
For all segments, the IF bandwidth for the linear/log
sweep (set with Avg key > IF Bandwidth) is set.
Power level
For all segments, the power level for the linear/log
sweep (set with Sweep Setup key > Power) is set.
Sweep delay
time
For all segments, 0 is set.
Sweep mode
For all segments, the sweep mode for the linear/log
sweep (set with Sweep Setup key > Sweep Mode) is
set.
Sweep time For all segments, the auto sweep time mode is set.
Segment
ON/OFF
For all segments, ON is set.
Sweep Delay/Sweep Time in Segment Sweep
