Measurement
445
Display the trigger menu.
Trigger
2. Set the trigger source to "manual."
Setting Description Key Operation
Set the trigger source to "manual." Trigger Source > Manual
3. Set the trigger mode for channel 1 to "continuous."
Setting Description Key Operation
Set channel 1 to the active channel.
Channel Next
Set the trigger mode to "continuous."
Continuous
4. Set the trigger mode for channels 2, 3, and 4 to "continuous"
according to the same procedure as in Step 3.
5. Execute the measurement.
Setting Description Key Operation
Generate a trigger event.
Trigger
6. Repeat the following procedure to execute auto scale for all of the
channels.
Setting Description Key Operation
Set the active channel.
Channel Next
Execute auto scale. Scale > Auto Scale
