E5071C
122
Reflection Tracking
(Er1,Er2,Er3,Er4)
Simplif
ied 4-
port
TRL
calibra
tion
Reflection
(open or
short)
Thru
Line
Match
Same as 4-port TRL
calibration
S11, S21, S31, [S41],
S12, S22, [S32],
[S42], S13, [S23],
S33, S43, [S14],
[S24], S34, S44
(Part of thru (or line)
and line (or match)
measurement can be
skipped)
High-
accuracy 4-
port
measurement
Effective for
non-coaxial
device
measurement
Simpler
procedure by
skipping
thru/line/mat
ch
measurement
