E5071C
2760
SCPI.TRIGger.OUTPut.POSition
Object type
Property (Read-Write)
Syntax
SCPI.TRIGger.OUTPut.POSition=Param
Param=SCPI.TRIGger.OUTPut.POSition
Description
This command sets/gets the position of the External Trigger Output Port.
Variable
Parameter Param
Description
Sets/Gets (after or before
measurement point) position of the
output trigger.
Data type Character string type (String)
Range
Select from either of the following:
• "AFTer": Generates a Pulse
(trigger) after the measurement
points.
• "BEFore": Generates a Pulse
(trigger) before the
measurement points.
Preset
value
"AFTer"
Examples
Dim TrigPos As String
TrigPos="BEFore"
SCPI.TRIGger.OUTPut.POSition=TrigPos
Related objects
SCPI.TRIGger.OUTPut.POLarity
SCPI.TRIGger.OUTPut.STATe
Equivalent key
Trigger > Position
Equivalent SCPI command
