SCPI.TRIGger.SEQuence.EXTernal.SLOPe
Object type
Property
Syntax
SCPI.TRIGger.SEQuence.EXTernal.SLOPe
Description
This command sets/gets the polarity of the External Trigger Input Port.
Variable
Parameter Param
Description
Sets/Gets polarity of the external input
trigger.
Data type Character string type (String)
Range
Select from either of the following:
• "POSitive": Sets/Gets Positive
polarity.
• "NEGative": Sets/Gets Negative
polarity.
Preset
value
"NEGative"
Examples
Dim InputTrigPol As String
InputTrigPol="NEGative"
SCPI.TRIGger.SEQuence.EXTernal.SLOPe=InputTrigPol
Related objects
SCPI.TRIGger.SEQuence.EXTernal.DELay
SCPI.TRIGger.SEQuence.EXTernal.LLATency.STATe
Equivalent key
Trigger > Ext Trig Input
Equivalent SCPI command
Syntax
:TRIGger[:SEQuence]:EXTernal:SLOPe {POSitive|NEGative}
:TRIGger[:SEQuence]:EXTernal:SLOPe?
