Programming
2797
:CALCulate:EYE:INPut:RTIMe:THReshold
Type
Command/Query
Syntax
:CALCulate:EYE:INPut:RTIMe:THReshold {T1_9|T2_8}
:CALCulate:EYE:INPut:RTIMe:THReshold?
Description
This command sets the rise time threshold for the simulated eye.
Parameter
Description Treshold levels define rise time
Data Type Character string type (String)
Range
T1_9: 10%-90%
T2_8: 20%-80%
Preset Value T1_9
Unit -
Resolution -
Query Response
{T1_9|T2_8}<newline><^END>
Examples
10 OUTPUT 717;":CALC:EYE:INP:RTIM:THR T1_9"
20 OUTPUT 717;":CALC:EYE:INP:RTIM:THR?"
30 ENTER 717;A$
Related Commands
:CALCulate:EYE:INPut:RTIMe:DATA
Equivalent GUI
Eye Mask > Rise Time (Under Bit Pattern)
