Agilent Technologies E5071C - Page 2585

E5071C
2812
:CALCulate:TRACe{Tr}:FORMat
Type
Command/Query
Syntax
:CALCulate:TRACe{Tr}:FORMat
{IMPedance|VOLT|MLOGarithmic|MLINear|REAL|IMAGinary|GDELay|SWR|
PHASe|UPHase|PPHase|SLINear|SLOGarithmic|SCOMplex|SMITh|SADMitta
nce|PLINear|PLOGarithmic|POLar}
:CALCulate:TRACe{Tr}:FORMat?
Description
This command sets trace format.
Parameter
De
scri
pti
on
Format for the trace.
Dat
a
Ty
pe
Character string type (String)
Ra
ng
e
For S-Parameter Measurement:
IMPedance|MLOGarithmic|MLINear|REAL|IMAGinary|GDELay|SWR|
PHASe|UPHase|PPHase|SLINear|SLOGarithmic|SCOMplex|SMITh|S
ADMittance|PLINear|PLOGarithmic|POLar
For Time Domain measurement:
IMPedance|VOLT|MLOGarithmic|MLINear|REAL
Pre
set
Val
ue
Depending on trace.
Uni
t
-
