:CALCulate:TRACe{Tr}:GATE:STARt
Type
Command/Query
Syntax
:CALCulate:TRACe{Tr}:GATE:STARt <numeric>
:CALCulate:TRACe{Tr}:GATE:STARt?
Description
This command sets start value for the gating function.
Parameter
Description Starting point of the gate
Data Type Double precision floating point type (Double)
Range -
Preset Value -10n
Unit -
Resolution -
Query Response
{numeric}<newline><^END>
Examples
10 OUTPUT 717;":CALC:TRAC1:GATE:STAR 2e-9"
20 OUTPUT 717;":CALC:TRAC1:GATE:STOP 6e-9"
30 OUTPUT 717;":CALC:TRAC1:GATE:TYPE BPAS"
40 OUTPUT 717;":CALC:TRAC1:GATE:STAT ON"
50 OUTPUT 717;":CALC:TRAC1:GATE:STAR?"
60 ENTER 717;A
Related Commands
:CALCulate:TRACe{Tr}:GATE:STOP
:CALCulate:TRACe{Tr}:GATE:TYPE
:CALCulate:TRACe{Tr}:GATE:STATe
Equivalent GUI
TDR/TDT > Gating > Start virtual knob OR
