Agilent Technologies E5071C - Page 2589

E5071C
2816
:CALCulate:TRACe{Tr}:GATE:STATe
Type
Command/Query
Syntax
:CALCulate:TRACe{Tr}:GATE:STATe {ON|OFF|1|0}
:CALCulate:TRACe{Tr}:GATE:STATe?
Description
This command sets state for the gating function.
Parameter
Description Activating the gating function
Data Type Boolean type (Boolean)
Range ON|OFF|1|0
Preset Value OFF
Unit -
Resolution -
Query Response
{1|0}<newline><^END>
Examples
10 OUTPUT 717;":CALC:TRAC1:GATE:STAR 2e-9"
20 OUTPUT 717;":CALC:TRAC1:GATE:STOP 6e-9"
30 OUTPUT 717;":CALC:TRAC1:GATE:TYPE BPAS"
40 OUTPUT 717;":CALC:TRAC1:GATE:STAT ON"
50 OUTPUT 717;":CALC:TRAC1:GATE:STAT?"
60 ENTER 717;A
Related Commands
:CALCulate:TRACe{Tr}:GATE:STARt
:CALCulate:TRACe{Tr}:GATE:STOP
:CALCulate:TRACe{Tr}:GATE:TYPE
Equivalent GUI
TDR/TDT > Gating > select the Gating check box OR
